XPLORERV X195

X195

All-Weather, All-Terrain Home Away from Everything!

XploreRv is taking off grid camping to another level… now with a facelift! Imperial continues to encompass the cold weather versatility we’ve become known for with the rugged capability of a true, off-road, off-grid camper. Remaining true to our roots, the X195 is capable in extreme cold as well as the summer heat. We’ve upgraded our chassis to improve tow-ability and handling, while maintaining strength and durability. Our customers have spoken, and we’ve listened… explore our Features/Packages to learn more!

KEY FEATURES

  • 4-Season Capability to -40˚F
  • Air Ride Suspension (21” of ground clearance to skid plate)
  • Fully Boxed Steel Perimeter Frame
  • Roof Mounted Solar System (240W up to 1240W) with 1-360Ah Lithium Battery Standard (upgradable to 1080Ah)
  • 60gal Fresh & 60gal Grey water tanks
  • Sleeps 3+



Standard Features (Model Specific)

  • Off-road reinforced, coated steel frame
  • Full Skid Plates
  • D-Ring recovery points
  • Fully insulated composite exterior walls with gelcoat surface
  • 1pc, fully insulated composite floor and fully walkable composite roof
  • Twin 20lb LP Fuel Tanks
  • Cold Weather LP Furnace
  • Low-profile, high efficiency 12V(DC) Roof-Mounted A/C
  • Bluetooth Speaker
  • Full Kitchen w/cooktop, refrigerator and kitchen sink
  • Full Bathroom w/shower and dry flush toilet
    (no black water tank to deal with in the back-country)
  • Upgraded 60 gallon fresh & 60 gallon grey water tanks
  • Convertible Dinette
  • King Size Bed (RV King) w/bedding
  • LED interior & exterior lighting
  • LED Light Bar
  • Conveniently placed 120V outlets & USB charging ports
  • Roof-mounted MaxxAir ventilation system
  • 270˚ Awning
  • Exterior Pass-Through Storage
  • Exterior 120V Power Outlet
  • RVIA Certified

Xtreme Package (Standard Upgrades)

  • Cruisemaster® ATX independent suspension
    (w/air bags, disc brakes, & parking brake)
  • 265/75 R16 Off Road Tires
  • Front Mounted Utility Box with LP & Generator Storage (generator not included)
  • On-board Air Compressor
  • Custom Roof rack
  • Cruisemaster® Articulating Hitch
  • Thermal Acrylic Windows
  • 360ah Lithium Battery (STAGE 1)
  • 240W Roof Mounted Solar System (STAGE 1)
  • 2000W Inverter & Monitor Panel
  • MPPT Solar Control & Battery Monitor
  • Heated/Insulated Water Storage Tanks
  • Outdoor Shower hookup
  • ARK® Heavy Duty Rolling Tongue Jack & Leveling Jacks
  • Customizable Rear Accessory Options

Customizable Options

Power Storage

  • STAGE 2 – 720Ah: (2) 360Ah Lithium Batteries
  • STAGE 3 – 1080Ah: (3) 360Ah Lithium Batteries

Solar Output

  • STAGE 2 – 740W: (7) Glass Solar Panels
  • STAGE 3 – 1240W: (11) Glass Solar Panels

Accessory Options

Rear
(unit accomodates 2 rear accessory mounting locations + hi-lift jack mounts)

  • Spare Tire Mount w/Full Size Spare
  • Jerry Can Mount (fits standard NATO Jerry Cans – not included)
  • Rear Utility Box
  • Auxillary Grid Panels (mounts to Front or Rear Utility Box)
  • Accessory Grid Panel (mounts to rear accessory bracket)
  • Hi-Lift Jack Mount (Hi-Lift Jack not included)

Front

  • Traction Board Mount
  • Auxillary Grid Panels (mounts to Front or Rear Utility Box)
  • Starlink Mounting Kit
  • Outdoor Kitchen

Download Features





SPECIFICATIONS:

X195

Overall Length (not including rear accessories) 26 ft 1 in
Overall Width (including fenders) 91 in
Overall Height 9 ft 9 in
Unit Weight 5500 lbs
Max Trailer Capacity (GVWR) 9920 lbs
Tongue Weight 560 lbs
Cargo Capacity 4420 lbs
Axle Weight Rating 9920 lbs
Tire Size 265/75 R16
Interior Height (floor-to-ceiling) 75.5 in
Interior Width (wall-to-wall) 78 in
Ramp Door Dimensions N/A
Ramp Door Weight Capacity N/A
Garage Dimensions (Min/Max) N/A
Fresh Tank Capacity 60 Gal
Grey Tank Capacity 60 Gal
Refrigerator Capacity 6.9 cu ft
LP Tank Capacity (2x) 20 lb
Furnace 14,300 BTU
Air Conditioner (12V) 6,824 BTU
Battery Capacity 360 Ah Lithium (x1)
Solar Output 240 W
Ground Clearance (+/- 5” for Air Adj) (to skid plate) 21 in
Sleeping Capacity 3+
Frame Material 2×6 Closed Tube Steel
Frame Coating Powder Coat w/e-coat Primer

Download Specs
