XPLORERV X145

X145

All-Weather, All-Terrain Couples Base Camp!

XploreRv is taking off-grid RVing to another level. Imperial continues to encompass the cold weather versatility we’ve become known for with the rugged capability of a true, off-road, off-grid camper. Remaining true to our roots, the X145 is capable in extreme cold as well as the summer heat. This single axle overland camper is smaller and easier to maneuver through the back country. With our updated cabin design, we have concentrated on improving our build precision as well as the quality of the components. View our Features/Packages list to learn more!

KEY FEATURES

    • 4-Season Capability to -40˚F
    • Air Ride Suspension (21” of ground clearance to skid plate)
    • Fully Boxed Steel Perimeter Frame
    • Roof Mounted Solar System (240W up to 740W) with 1-360Ah Lithium Battery Standard (upgradable to 1080Ah)
    • 60gal Fresh & 60gal Grey water tanks
    • Sleeps 2+

VIDEO

COLORS

EXTERIOR

INTERIOR

OPTIONS

DIMENSIONS

Overall Length (not including rear accessories) 21 ft 7 in
Overall Width (including fenders) 91 in
Overall Height 9 ft 9 in
Unit Weight 4400 lbs
Max Trailer Capacity (GVWR) 6172 lbs
Tongue Weight 450 lbs
Cargo Capacity 1772 lbs
Axle Weight Rating 6172 lbs
Tire Size 265/75 R16
Interior Height (floor-to-ceiling) 75.5 in
Interior Width (wall-to-wall) 78 in
Ramp Door Dimensions N/A
Ramp Door Weight Capacity N/A
Garage Dimensions (Min/Max) N/A
Fresh Tank Capacity 60 Gal
Grey Tank Capacity 60 Gal
Refrigerator Capacity 3 cu ft
LP Tank Capacity (2x) 20 lb
Furnace 14,300 BTU
Air Conditioner (12V) 6,824 BTU
Battery Capacity 360 Ah Lithium (x1)
Solar Output 240 W
Ground Clearance (to skid plate at ride height) 21 in
Sleeping Capacity 2+
Frame Material 2×6 Closed Tube Steel
Frame Coating Powder Coat w/e-coat Primer
Download Features

SPECIFICATIONS

STANDARD FEATURES

Off-road reinforced, coated steel frame
Full Skid Plates
D-Ring recovery points
Fully insulated composite exterior walls with gelcoat surface
1pc, fully insulated composite floor and fully walkable composite roof
Twin 20lb LP Fuel Tanks
Cold Weather LP Furnace
Low-profile, high efficiency 12V(DC) Roof-Mounted A/C
Bluetooth Speaker
Full Kitchen w/cooktop, refrigerator and kitchen sink
Full Bathroom w/shower and dry flush toilet
(no black water tank to deal with in the back-country)
Upgraded 60 gallon fresh & 60 gallon grey water tanks
Convertible Dinette
Full Size Bed (RV Full) w/bedding
LED interior & exterior lighting
LED Light Bar
Conveniently placed 120V outlets & USB charging ports
Roof-mounted MaxxAir ventilation system
270˚ Awning
Exterior Pass-Through Storage
Exterior 120V Power Outlet
RVIA Certified

Xtreme Package (Standard Upgrades)

Cruisemaster® ATX independent suspension (w/air bags, disc brakes, & parking brake)
265/75 R16 Off Road Tires
Front Mounted Utility Box with LP & Generator Storage (generator not included)
On-board Air Compressor
Custom Roof rack
Cruisemaster® Articulating Hitch
Thermal Acrylic Windows
360ah Lithium Battery (STAGE 1)
240W Roof Mounted Solar System (STAGE 1)
2000W Inverter & Monitor Panel
MPPT Solar Control & Battery Monitor
Heated/Insulated Water Storage Tanks
Outdoor Shower hookup
ARK® Heavy Duty Rolling Tongue Jack & Leveling Jacks
Customizable Rear Accessory Options

Download Features

CUSTOMIZABLE OPTIONS

Power Storage

STAGE 2 – 720Ah: (2) 360Ah Lithium Batteries

Solar Output

STAGE 2 – 740W: (7) Glass Solar Panels

ACCESSORY OPTIONS

Rear
(unit accomodates 2 rear accessory mounting locations + hi-lift jack mounts)

Spare Tire Mount w/Full Size Spare
Jerry Can Mount (fits standard NATO Jerry Cans – not included)
Rear Utility Box
Auxillary Grid Panels (mounts to Front or Rear Utility Box)
Accessory Grid Panel (mounts to rear accessory bracket)
Hi-Lift Jack Mount (Hi-Lift Jack not included)

Front

Traction Board Mount
Auxillary Grid Panels (mounts to Front or Rear Utility Box)
Starlink Mounting Kit
Outdoor Kitchen
